Description
23.8-inch 4K Monitor
UHD panel, 94.1% DCI-P3
BM-U245 adopts a 23.8-inch 10bit LCD
panel, UHD 3840×2160 resolution, 300nits LED
backlight, 1000:1 contrast, 94.1% DCI-P3 color gamut. The viewing angle is H178° / V178°
› 23.8-inch LCD Panel, 3840×2160 resolution
› 12GSDI 4-in 4-out, 8K input ready, HDMI2.0 input
› 12GSDI via SFP Fiber input (Optional)
› ST2110 IP via SFP Fiber input (Optional)
› 3DLUT Auto Self-calibration without PC
› Audio/Video 0 latency for lip-sync
› HLG/PQ/S-log3 HDR EOTF
› Payload ID auto setting
› Built-in Multi camera Delog LUTs
› User 3DLUTs upload via USB
› Waveform / Vector / Histogram
› Focus assist / False color / Zebra
› 16-ch audio meters / Lissajous
› IP webserver remote control
› TSL UMD and text TALLY display
› USB firmware upgrade
