AJA Colorbox

£2,150.00

Category:

Description

ColorBox from AJA is a compact, high-performance converter for color managed workflows designed to specifically meet the conversion needs of broadcast, live events, and on-set applications.  Supporting Standard Dynamic Range (SDR), High Dynamic Range (HDR), and Wide Color Gamut (WCG) signals, it utilizes 12G-SDI and HDMI 2.0 for single wire 4K/UltraHD HDR up to 4:2:2 10-bit 60p or 4:4:4 12-bit 30p with a unique color processing pipeline.



  • 12-bit 4:4:4 12G-SDI I/O for up to 4K/UltraHD HDR/WCG 30p
  • 10-bit 4:2:2 12G-SDI I/O for up to 4K/UltraHD HDR/WCG 60p
  • 12-bit 4:4:4 HDMI 2.0 output for up to 4K/UltraHD HDR/WCG 30p
  • 10-bit 4:2:2 HDMI 2.0 output for up to 4K/UltraHD HDR/WCG 60p
  • Ultra low latency, less than ½ a video line
  • Extensive AJA Color Pipeline built around the 33pt. 3D LUT processor with tetrahedral interpolation
    • 7x nodes plus Overlay
      • 1x 3D LUT processor, user configurable as 3D LUT or Dynamic
      • 4x 1D LUT processors, user configurable as 1D LUT, Dynamic, or Color Corrector
      • 2x 3×3 Matrix processors, user configurable as 3×3 Matrix, Dynamic, or ProcAmp
    • Supports industry standard file types, no conversion to proprietary format required
    • Configurable Colorspace, Range, and Transfer Characteristic
    • Full frame LUT processing
  • Five Color Processing Pipelines
    • AJA Color
    • Colorfront Mode
    • ORION-CONVERT Mode (Licensable option)
    • BBC HLG LUT Mode (Licensable option)
    • NBCU LUTs
  • Video Preview in web user interface for confidence monitoring
  • Built in Frame Store
    • Up to 4K/UltraHD frame capture and recall
    • Capture pre or post processed images
  • Test Pattern up to 4K/UltraHD, 9x test patterns built-in
  • Overlay information on output
    • User Text
    • Input and Output signal information
    • Pipeline Configuration
    • Overlay can be captured with image for future reference
  • Onboard library for file management
    • 16x 1D LUTs
    • 16x 3D LUTs
    • 16x 3×3 Matrices
    • 16x Images
  • Preset Management, 10 per Pipeline plus Startup Preset
  • ANC metadata pass-through
  • Embedded audio pass-through, SDI 16-ch. and HDMI 8-ch.
  • Compact; 4 units can fit in just 1RU
  • Ultra quiet fan operation
  • Lightweight
  • Robust locking 4-pin mini-XLR power connector, DC power
  • On/Off button so you can save power when not in use
  • Select button used to bypass video processing
  • Extensive API for 3rd party control integrations
  • Embedded web server for remote control
  • Configure IP Address via USB port and supplied AJA eMini-Setup software for PC/Mac
  • Three year warranty



LICENSE OPTIONS

ColorBox License for ORION-CONVERT  – £710

Clorox License for BBC HLG LUTs – £150
