Description
23.8-inch QLED WCG Panel
FHD, 100% DCI-P3 Coverage
BM-H245 adopts a 23.8-inch1920x1080 QLED panel, 100% DCI-P3 coverage wide color gamut, 400nits LED backlight, 1000:1 contrast, H/V 178° viewing angle for broadcast and film productions.
› 23.8-inch 1920×1080 QLED Panel
› 100% DCI-P3 wide color gamut coverage
› VICO 1.97 A-class Eye Protecting LCD
› 12G-SDI, 4x3G-SDI, HDMI2.0 4K input
› 4-ch SDI/HDMI mixed multiview
› 2-ch SDI/HDMI PBP or PIP view
› Multi Color Gamut & HDR/SDR Viewing
› Payload ID auto setting
› 18-bit internal color processing
› Audio/Video Zero latency for lip-sync
› 3DLUT Auto Self-calibration without PC
› Built-in Multi camera Delog LUTs
› User 3DLUTs upload via USB
› Waveform / Vector / Histogram / Eye pattern
› Focus assist / False color / Zebra
› 16-ch audio meters / Lissajous pattern
› 5.1 & 7.1 surround sound phase pattern
› IP webserver remote control
› TSL UMD and text TALLY display
› USB firmware upgrade
